M24-CFLS-ATX06

主要特点

    l Intel® LGA 1151 Socket: Ready for 9th/8th gen Core™ i9/i7/i5/i3 & Pentium®/Celeron® processor

    l Support 4x DDR4 2666MT/s U-DIMM, Dual Channel, up to 128GB

    l Support VGA/HDMI®/DP/eDP Tri-display

    l 1x M.2 E-Key 2230 Slot, 1x M.2 M-Key 2242/2280 Slot

    l 2x PCIe 3.0 X16 Slots(X8 Singal), 3x PCIe 3.0 X4 Slots(X4 Signal), 2x PCI Slots

    l Support TPM 2.0 encryption technology


      http://decenta.junui.cn/upload/20240415/dbe548aeb9644b6e69621ae151585d63.png

下载
个人信息

姓名*

邮箱地址*

手机号码*

公司*

文件下载
1 全选 0
一键下载
  • 产品概述
  • 技术参数
  • 图片尺寸
  • 订货型号
  • 说明书
  • 产品型录

Decenta ATX06 is a standard ATX form factor motherboard, which is built on Intel® Q370/B360 chipset.  It has multiple expansion slots and rich I/O interfaces, making it widely used in Industrial automation, embedded systems, communication equipment, industrial servers and other scenarios.

http://decenta.junui.cn/upload/20250331/02efdc41fc70391d4998994c3a62faca.png

http://decenta.junui.cn/upload/20250331/ac17a4cf2953b6fd79712a8ad010c455.png

http://decenta.junui.cn/upload/20250331/079c665c132ea42a559f2e4ebc7c1d88.png
